Low Insertion loss
High Channel
Isolation
Low Polarization
Dependent Loss
Fiber Amplifier Long-hual
Metro
Access and FTTxCATV Fiber Optic Links
Operating WavelengthR:Reflect Band | 1:T1550 R1310/1490 3:T1310 R1490/1550 | ||
Insertion Loss(dB) | Pass Channel | <0.6 | |
Reflect | <0.4 | ||
Isolation | Pass Channel | >30 | |
Reflect | >17 | >20 | |
PDL(dB) | <0.1 | ||
PMD(dB) | <0.1 | ||
Directivity(dB) | >50 | ||
Return Loss(dB) | >45 | ||
Maximun Optical Power Handing(mW) | 500 | ||
Operating Temperature(。C) | -5 〜+70 | ||
Storage Temperature(C ) | -40〜+85 | ||
Fiber Type | SMF-28e fiber Or Others | ||
Dimension(mm) | 5.5x34mm | 90*20*10 | |
Note:Customization is available.Specified without connector，and add an additional 0.2dB loss per connector. | |||
