The product is applied in radio frequency transmission in wireless communication, broadcasting and related electronic equipment or in circuit-closed TV system, share-antenna system branch line, subscriber line andother electronic facility.
Conductor | MATERIAL | BC/CCS |
Nom.Dia. | 20AWG | |
Dielectric | MATERIAL | Foam PE |
Nom.Dia. | 3.66mm | |
Shield | MATERIAL | ALFoil+AL Braiding |
COVERAGE | 40%-95% | |
Jacket | MATERIAL | PVC/PE |
Nom.Thick. | 0.80mm | |
Nom.Dia. | 6.10mm |
Nominal Impedance(ohm) | 75±3 | ||
Nominal Velocity of propagation(%) Nominal Capacitance(pf/m) | 84 | ||
82 | |||
Spark Test(VAC) | 2500 | ||
SRL(dB) | 20 | 20 | |
Attenuation [68°f(20℃)] | Frequency（MHz） | Maximum (dB/100m) | |
150 | 4.10 | ||
280 | 5.60 | ||
350 | 6.30 | ||
400 | 6.90 | ||
800 | 10.20 | ||
900 | 11.10 | ||
1200 | 13.40 | ||
1500 | 15.30 | ||
10D-FB is part of Xingfa's FB-series coaxial cable offering. When a project specifies an FB-series cable, the final choice should be based on the required electrical characteristics, physical construction and installation conditions rather than the model number alone.
Buyers considering another FB-series construction can review Xingfa's 8D-FB coaxial cable, which is currently specified with a 2.80 ± 0.05 mm BC/CCS conductor, approximately 11.10 mm overall diameter and published attenuation of 12.80 dB/100m at 900 MHz.
For projects where a smaller cable construction is appropriate, Xingfa's 5D-FB coaxial cable currently uses a 1.80 ± 0.05 mm BC/CCA conductor and an approximately 7.5 mm overall diameter.
Before changing between 5D-FB, 8D-FB and 10D-FB, confirm the equipment specification, operating frequency, cable length, allowable attenuation, connector compatibility and installation space with the technical team.
