Low Insertion Loss
Wide pass band
High Channel Isolation
High Stability and reliability
Epoxy-free on Optical Path
Line Monitoring
WDM Network
Tel ecommuni cati on
Cellular Application
Fiber Optical amplifier
Acess Network
Parameter | Specification | |
Channel Wavelength (nm) | 1270-1610 | |
Center wavelength Accuracy (nm) | ±0.5 | |
Channel Spacing (nm) | 20 | |
Channel Passband (@-0.5dB bandwidth (nm) | >13 | |
Pass Channel Insertion Loss (dB) | <0.6 | |
Channel Ripple (dB) | <0.3 | |
Isolation (dB) | Pass Channel | >50 |
Reflect Channel | >15 | |
Insertion Loss Temperature Sensitivity (dB/°C) | <0.005 | |
Polarization Dependent Loss (dB) | <0.1 | |
Polarization Mode Dispersion | <0.1 | |
Directivity (dB) | >50 | |
Return Loss (dB) | >45 | |
Maximum Power Handling (mW) | 500 | |
Operating Temperature (C) | -20~+85 | |
Storage Temperature (C) | -40~+85 | |
Package dimension (mm) | 05.5 x L38(forbare fiberor900umLoosetube) | |
