The product is applied in RF signal transmission for CCTV systems, shared-antenna systems (MATV), and other video or broadcasting equipment.
Conductor | MATERIAL | BC/CCS |
Nom.Dia.(mm) | 0.50±0.05 | |
Dielectric | MATERIAL | Foam PE |
Nom.Dia.(mm) | 2.95±0.05 | |
Shield | MATERIAL | BC Braiding |
COVERAGE | 40%-95% | |
Jacket | MATERIAL | PVC/PE |
Nom.Thick. (mm) | 0.80±0.05 | |
Nom.Dia. (mm) | 5.00±0.05 |
Nominal Impedance(ohm) | 75±3 | |
Nominal Velocity of propagation(%) Nominal Capacitance(pf/m) | 83 53 | |
Spark Test(VAC) | 2500 | |
SRL(dB) | 20 | |
Attenuation [68°f(20℃)] | Frequency（MHz） | Maximum (dB/100m) |
5 | 1.15 | |
55 | 3.28 | |
187 | 5.57 | |
300 | 8.53 | |
450 | 12.13 | |
600 | 14.76 | |
750 | 17.72 | |
865 | 19.30 | |
1000 | 20.94 | |
