Optical cables are mainly used in the transmission of optical signals in telecommunications networks

1. Package: wood drum

2. Certificate: CE ROHS ETL UL CPR

3. Free samples

4. Provide test report

5. Stable quality, complete testing equipment

Specification

Temperature Range

Transport/Storage Temp	Installation Temp	Operation Temp
-40℃~+70℃	-30℃~+50℃	-40℃~+70℃

Structural Characteristic

Fiber Count	2~288
Loose Tube	Colored Fiber In Pbt Loose Tube, Filled With Fiber Gel
Central Strength Member	Steel Wire Or Frp(Fiber Reinforce Plastic Rod)
Waterproof Layer	Cable Core Filled With Cable Gel Or Water Blocking Tape, Water Blocking Yarns
Corrugated Aluminum-Plastic Tape	Enhances Cable's Moisture Proof Performance And Ensure Cable's Flexibility And Anti-Bending Capability.
Sheath	Polyethylene(PE)

Technical Data(Gyfta)

Fiber Count	Cable Outer Dia (Mm)	Cable Weight (Kg/Km)	Min.Bending Radius(Mm)		Permissible Tensile Force（n）		Permissible Pressure Force（n/100mm）
Fiber Count	Cable Outer Dia (Mm)	Cable Weight (Kg/Km)	Static	Dynamic	Short Term	Long Term	Short Term	Long Term
2-36	10.5	93	10d	20d	1500	600	1000	300
38-72	11.1	105	10d	20d	1500	600	1000	300
74-84	11.8	118	10d	20d	1500	600	1000	300
86-96	12.4	130	10d	20d	1500	600	1000	300
98-108	13.1	150	10d	20d	1500	600	1000	300
132-144	15.2	200	10d	20d	1500	600	1000	300
288	18.2	305	10d	20d	1500	600	1000	300
Note："d" Is Cable Diameter
