The product is applied in RF transmission for wireless communication systems, GPS, WLAN, broadband networks, antenna feeders, and various electronic equipment requiring low-loss, high-frequency signal delivery.
Conductor | MATERIAL | BC |
Nom.Dia.(mm) | 1.42±0.05 | |
Dielectric | MATERIAL | Foam PE |
Nom.Dia.(mm) | 3.81±0.05 | |
Shield | MATERIAL | ALFoil+AL Braiding |
COVERAGE | >90% | |
Jacket | MATERIAL | PE |
Nom.Thick.(mm) | 0.80±0.05 | |
Nom.Dia.(mm) | 6.10±0.05 |
Nominal Impedance(ohm) | 50±3 | ||
Nominal Velocity of propagation(%) Nominal Capacitance(pf/m) | 83 24.2 | ||
Spark Test(VAC) | 2500 | ||
SRL(dB) | 20 | 20 | |
Attenuation [68°f(20℃)] | Frequency（MHz） | Maximum (dB/100m) | |
30 | 4.4 | ||
50 | 5.7 | ||
150 | 9.90 | ||
220 | 12.00 | ||
450 | 17.30 | ||
900 | 24.80 | ||
1500 | 32.4 | ||
