Product info

Interface
According to IEC 61169-16
Electrical
Characteristic Impedance 50 ohm
Frequency Range 0-3GHz
VSWR ≤1.15
Dielectric Withstanding Voltage ≥2500V RMS,50Hz,at sea level
Dielectric Resistance ≥5000MΩ
Contact Resistance Center Contact ≤1mΩ
Outer Contact ≤0.25mΩ
Mechanical
Durability Mating cycles ≥500
Material and plating Material plating
Body Brass Ni
Insulator PTFE
Center conductor Phosphor bronze Au
Environmental
Temperature Range -40℃~+85℃
Drafted by:   W.b Approved by:Q.h
